AXLE
Vertical-axis pump with bearings in a watertight chamber, the size of which allows the lower part of the shaft to be cantilevered without supports immersed in the liquid

CONNECTION
Using V-belts with the ability, thus, by varying the size and type of belts and pulleys, increase or decrease the flow / head of the pump itself (depending on the number of revolutions that will received). Depending on the required performance, the supplied pump type can also be supplied with a direct connection (type PGM). Both versions come with a protective cover.

BODY
Made of cast iron, divided into two halves with a protective wear-resistant molded coating from our special composition, consisting of replaceable and externally adjustable casings, which allows for quick and convenient replacement and elimination any clearances caused by normal wear and tear.

DELIVERY ELBOW
With replaceable rubber coupling for connecting the pump to the discharge pipe

IMPELLER
Open type anti-clogging, made of a steel core coated with a special anti-abrasive compound.

SUCTION FILTER
And of cast iron, of the appropriate size and shape for suction of liquid.

EYE SUPPORT UNIT
Usually included because they are required for lifting operations.

PUMP RETAINER
Bracket for fixing the pump to the wall.

EXTENSION FOR SUCTION FILTER
On request, an extension can be inserted between the suction filter and the bottom of the housing to increase the distance between the bottom bearing and the liquid level, or to keep the motor outside the reservoir.
